This is a spray ball only, intended for use with a K-Ball Assembly.
Wide, flat shaped spray with low impact. The spray is deflected 75° from the centerline of the nozzle.
Injection molded spray ball, intended for use in a K-Ball Assembly
The three different variations of the BPH spray nozzle balls are color coded by flowrate for easier identification
| Model | Equiv. Orif. Dia. () (inches) | Capacities at Various Pressures (USGPM) | Spray Angle (psi) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 psi | 5 psi | 7 psi | 10 psi | 15 psi | 20 psi | 25 psi | 30 psi | 40 psi | 50 psi | 7 psi | 20 psi | ||
| BFL5 | 0.076 | 1.04 | 0.35 | 0.42 | 0.50 | 0.61 | 0.71 | 0.79 | 0.87 | 1.00 | 1.12 | 114° | 130° |
| BFL10 | 0.110 | 0.55 | 0.71 | 0.84 | 1.00 | 1.22 | 1.41 | 1.58 | 1.73 | 2.00 | 2.24 | 134° | 146° |
| BFL18 | 0.149 | 0.99 | 1.27 | 1.51 | 1.80 | 2.20 | 2.55 | 2.85 | 3.12 | 3.6 | 4.0 | 130° | 142° |
| BFL24 | 0.167 | 1.31 | 1.70 | 2.01 | 2.40 | 2.94 | 3.4 | 3.8 | 4.2 | 4.8 | 5.4 | 121° | 136° |
| BFL30 | 0.183 | 1.64 | 2.12 | 2.51 | 3.00 | 3.7 | 4.2 | 4.7 | 5.2 | 6.0 | 6.7 | 120° | 133° |
| BFL40 | 0.218 | 2.19 | 2.83 | 3.3 | 4.0 | 4.9 | 5.7 | 6.3 | 6.9 | 8.0 | 8.9 | 130° | 144° |
